Hikvision · Prime Pass Speed Gates

Hikvision DS-K6B411TX Series Speed Gate

The Hikvision DS-K6B411TX Series is a speed gate from Hikvision's access control range.

Authentication Mode: Card (EM/M1), face, QR code (Optional)
Throughput: 20 to 60 persons per minute*
Lane Width: 550 mm to 1,100 mm
Application Environment: Indoor / Outdoor

AIVIZ supplies and installs the DS-K6B411TX Series in Dubai and across the UAE, with face recognition terminals, readers and software for each lane. Call +971 50 202 5767.

DS-K6B411TX Series specifications

As published in Hikvision's access control brochure. Ask us which version suits your doors.

Motor Type: Brushless Motor
Built in Access Controller: Yes
Super Capacitor (Emergency Open): Yes
Built-in Face Recognition Camera: 2 MP FOV: Horizontal: 75°, Vertical: 139°
Additional Loudspeaker and Keyfob Board: Built-in wireless keyfob (433 MHz / 868 MHz, within 50 m), wired remote control pad
Authentication Mode: Card (EM/M1), face, QR code (Optional)
Communication Interface: TCP/IP × 1 RS485 × 2 Exit button × 2 Alarm out × 4 USB × 2 Fire alarm input × 2 Case input × 2
Safety Detectors: 6 dToF
Throughput: 20 to 60 persons per minute*
Capacity: 200,000 cards 100,000 faces 100,000 events
MCBF: ≥ 5 million times
Barrier / Wing Material: Stainless steel pipe, acrylic glass
Pedestal Material: SUS304 stainless steel 1.2 mm
Lane Width: 550 mm to 1,100 mm
Dimension (L × W × H) per Pedestal: With package: 1,405 mm × 345 mm × 1,195 mm Without package: 1,205 mm × 199 mm × 1,072 mm
Application Environment: Indoor / Outdoor
